Model Name			KSV-18TPINV-SW
Type			Cooling only
Control type			Remote
Power supply		Ph-V-Hz	1Ph-220-240V~50Hz
Voltage Range		V	165~265
Cooling	Capacity	Btu/h	18000（3412~19107）
	Capacity	W	5275（1000~5600）
	Rated power Input	W	1638（300~2000）
	Rated current	A	7.6（1.4~10）
	EER	W/W	3.22
	Max power Input	W	2000
	Max current	A	10.0
Indoor coil	a.Number of rows		2
	b.Tube pitch(a)x row pitch(b)	mm	21x12.7
	c.Fin spacing	mm	1.4
	e.Tube outside dia.and type	mm	Φ7,innergroove
	f.Coil length x height x width	mm
	g.Number of circuits		3 in 3 out
Outdoor coil	a.Number of rows		1
	b.Tube pitch(a)x row pitch(b)	mm	21x18.2
	c.Fin spacing	mm	1.3
	e.Tube outside dia.and type	mm	Φ7,innergroove
	f.Coil length x height x width	mm
	g.Number of circuits		1 in 1 out
Indoor unit	Dimension(W*D*H)	mm	910×294×206
	Packing   (W*D*H)	mm	979×372×277
	Net/Gross weight	Kg	9/12
Outdoor unit	Dimension(W*D*H)	mm	795×305×549
	Packing  (W*D*H)	mm	818×325×520
	Net/Gross weight	Kg	25/30（with pipe）
Refrigerant piping	Liquid side/ Gas side	mm(inch)	φ6(1/4")/φ9.52(3/8")
	Max. refrigerant pipe length	m	15
	Max. difference in level	m	5
Pressure	High(DP)	MPa	4.5
	Low(SP)	MPa	1.9
Refrigerant			R410A/0.78
Ambient temperature		℃	18~50
Suitable area		m2	20~35
Connecting Wiring	Size x Core number		4×1.5
Power supply cord			1.5mm²
Qty 40'HQ			232

​

N/A

N/A

N/A

10 Years’ Compressor & 02 Years’s Parts & Service.
