KSV-24RINV KELVINATOR 2TON INVERTER AC
Reviews
Model:
KSV-24RINVSHARE:
Model | KSV-24RINV | ||
Type | Split | ||
Control type | Cooling Inverter | ||
Power supply | Ph-V-Hz | 1Ph-220-240V~50Hz | |
Voltage Range | V | 155~265 | |
Capacity | Btu/h | 24000(4094~25590) | |
Capacity | W | 7034(1200~7500) | |
Rated power Input | W | 2198(300~2450) | |
Rated current | A | 9.9(1.4~13.0) | |
Max power Input | W | 2450 | |
Max current | A | 13 | |
Compressor | Model | ATN150042UFZ | |
Type | Rotary | ||
Brand | GMCC | ||
Compressor type | T1/T3 | T1 | |
Capacity | Btu/h | 15286 | |
Input | W | 1120 | |
Rated current(RLA) | A | 7.75 | |
Locked rotor Amp(LRA | A | / | |
Capacitor | UF | / | |
Refrigerant oi/oil charg | ml | ESTEL OI VG74-450 | |
Indoor unit | Dimension(W*D*H) | mm | |
Packing (W*D*H) | mm | 1165x405x295 | |
Outdoor unit | Dimension(W*D*H) | mm | 920x380x699 |
Packing (W*D*H) | mm | 960x430x732 | |
Pressure | High(DP) | MPa | 4.5 |
Low(SP) | MPa | 1.9 | |
Refrigerant | R22/R410a/R32 | R-32 | |
Ambient temperature | ℃ | 0~43 | |
Model | KSV-24RINV | ||
Type | Split | ||
Control type | Cooling Inverter | ||
Power supply | Ph-V-Hz | 1Ph-220-240V~50Hz | |
Voltage Range | V | 155~265 | |
Capacity | Btu/h | 24000(4094~25590) | |
Capacity | W | 7034(1200~7500) | |
Rated power Input | W | 2198(300~2450) | |
Rated current | A | 9.9(1.4~13.0) | |
Max power Input | W | 2450 | |
Max current | A | 13 | |
Compressor | Model | ATN150042UFZ | |
Type | Rotary | ||
Brand | GMCC | ||
Compressor type | T1/T3 | T1 | |
Capacity | Btu/h | 15286 | |
Input | W | 1120 | |
Rated current(RLA) | A | 7.75 | |
Locked rotor Amp(LRA | A | / | |
Capacitor | UF | / | |
Refrigerant oi/oil charg | ml | ESTEL OI VG74-450 | |
Indoor unit | Dimension(W*D*H) | mm | |
Packing (W*D*H) | mm | 1165x405x295 | |
Outdoor unit | Dimension(W*D*H) | mm | 920x380x699 |
Packing (W*D*H) | mm | 960x430x732 | |
Pressure | High(DP) | MPa | 4.5 |
Low(SP) | MPa | 1.9 | |
Refrigerant | R22/R410a/R32 | R-32 | |
Ambient temperature | ℃ | 0~43 | |
N/A
N/A
N/A
10 Years Compressor & 02 Years Parts & Service Warranty
N/A
