Rangs IPS 750VA
Reviews
Model:
RIPS-750VA-TPEMI From 3817 Tk/month
Available Bank EMI
SHARE:
Model | RIPS-750VA-TP |
Output Voltage | 220V Nominal |
Running Load Batt., Current | 40A+/-2Amp |
Over Load batt. Current | 44A+/-2Amp |
O/P Waveform | Modified Sq Wave |
O/P Frequency (N/L & F/L) | 50.0+/-0.5Hz |
Running bulb Load | 600W |
Low batt. alarm | 10.8V+/-0.2V |
Re-tries during Over Load Normal mode | 5 |
Mains AC mode | |
Mains AC Low cut UPS mode | 180±10V |
Mains AC High cut UPS mode | 265±10V |
Change over time Mains to backup | <10ms |
Change over time backup to Mains | <10ms |
Output Frequency | SAME AS I/P |
Output Waveform | SAME AS I/P |
Mains AC Low cut normal mode / IPS mode | 100±10V |
Mains AC High cut normal mode / IPS mode | 290±10V |
Battery charging voltage (Automatic selection) | 14.6V+/-0.2V/13.7V+/-0.2V 14.6V+/-0.2V/13.7V+/-0.2V (per batt.) |
Battery charging current (Automatic selection) | 11+/-1A |
Visual Indications | |
On/Off switch off (With mains within range) | Mains LED blinks |
On/Off switch on (with mains within range) | Mains LED continuous glow |
Mains out of range | Mains LED off |
Battery charging | Charging LED blinks |
Battery charged | Charging LED continuous glow |
Output Waveform | Backup LED continuous glow |
Low battery occurs | Low batt. LED blinks |
Low battery shutdown | Low batt. LED continuous glow |
Overload occurs | Overload LED blinks |
Overload shutdown | Overload LED continuous glow |
Mains fuse blown | Mains on continuous glow |
TSC protection | Charging LED continues glow |
Audio Indication (Buzzer) | |
Self Test | One buzzer beep |
Overload occurs | Beep-Beep |
Low battery occurs | Delay 90sec beep 1 sec |
Over temperature shutdown | Continuous buzzer |
Mains fuse blown | Continuous buzzer |
Model | RIPS-750VA-TP |
Output Voltage | 220V Nominal |
Running Load Batt., Current | 40A+/-2Amp |
Over Load batt. Current | 44A+/-2Amp |
O/P Waveform | Modified Sq Wave |
O/P Frequency (N/L & F/L) | 50.0+/-0.5Hz |
Running bulb Load | 600W |
Low batt. alarm | 10.8V+/-0.2V |
Re-tries during Over Load Normal mode | 5 |
Mains AC mode | |
Mains AC Low cut UPS mode | 180±10V |
Mains AC High cut UPS mode | 265±10V |
Change over time Mains to backup | <10ms |
Change over time backup to Mains | <10ms |
Output Frequency | SAME AS I/P |
Output Waveform | SAME AS I/P |
Mains AC Low cut normal mode / IPS mode | 100±10V |
Mains AC High cut normal mode / IPS mode | 290±10V |
Battery charging voltage (Automatic selection) | 14.6V+/-0.2V/13.7V+/-0.2V 14.6V+/-0.2V/13.7V+/-0.2V (per batt.) |
Battery charging current (Automatic selection) | 11+/-1A |
Visual Indications | |
On/Off switch off (With mains within range) | Mains LED blinks |
On/Off switch on (with mains within range) | Mains LED continuous glow |
Mains out of range | Mains LED off |
Battery charging | Charging LED blinks |
Battery charged | Charging LED continuous glow |
Output Waveform | Backup LED continuous glow |
Low battery occurs | Low batt. LED blinks |
Low battery shutdown | Low batt. LED continuous glow |
Overload occurs | Overload LED blinks |
Overload shutdown | Overload LED continuous glow |
Mains fuse blown | Mains on continuous glow |
TSC protection | Charging LED continues glow |
Audio Indication (Buzzer) | |
Self Test | One buzzer beep |
Overload occurs | Beep-Beep |
Low battery occurs | Delay 90sec beep 1 sec |
Over temperature shutdown | Continuous buzzer |
Mains fuse blown | Continuous buzzer |
N/A
N/A
N/A
01 Year Standard Warranty
