Type

Direct Cool

Capacity :

Gross Volume (Outer Dimension, Manufacturer declared)

260 Ltr.

Net Volume

220 Ltr.

Performance :

Climatic Type (SN, N, ST, T)

N~ST

Rated Operating Voltage and Frequency

220-240V~ and 50Hz

Compressor Input Power (Watt)

V 0401-132
V 0501-111

Compressor Type

RSCR

Cooling Effect

Freezer Cabinet Less than -18?
Refrigerator Cabinet 0? to +5?

Energy Rating

5 star (BDS 1850:2012)

General Features :

Temperature Control (Electronic/ Mechanical)

Mechanical

Defrosting (Automatic/ Manual)

Manual

Reversible Door

No

Handle (Recessed/ Grip)

Recessed

Lock

Yes

Refrigerant

V 0401-R600a
V 0501-R600a

Thermostat

RoHS Certified

Condenser

100% Copper

Capillary

Copper

Polyurethane foam blowing agent

Cyclopentene
[Eco-friendly (100% CFC &
HCFC Free) Green Technology]

Recommended voltage stabilizer capacity

1000VA

Refrigerator Compartment :

Shelf (Material/No.)

Wire/3

Door Pocket

4

Interior Lamp

Yes

Vegetable Box

Yes/1

Vegetable Box Cover

Yes

Egg Case

Yes/ 1

Can Storage Dispenser

No

Deodorizer

No

Freezer Compartment :

Shelf (Material/ No.)

Wire/2

Drawer

No

Door Basket

No

Interior Lamp

No

Dimensions (Net) :

Width/mm

545

Depth/mm

605

Height/mm

1760

Packing :

Width/mm

580

Depth/mm

645

Height/mm

1770

Weight/Kg - Net/Packing (±2 KG)

51/58

Loading Capacity- 40HQ/ 40Ft/ 20Ft

103/ 75/ 36
